EVI series air source heat pump is specially designed according to cold climate features. Its core philosophy is to solve the user’s home heating during the cold climate in winter and spring, to make cooling in hot summer and autumn. At the same time of heating and cooling, it provides sanitary hot water all over the year. So all requirement of heating, cooling, sanitary hot water can be realized with only one heat pump.
AXAI-15 Zeus 6Kw-8Kw-11Kw-16Kw
| TECHNICAL DATA | 06 | 08 | 11 | 14 | ||
| Heating | Nominal capacity | kW | 6.43 | 8.66 | 10.83 | 14.2 |
| Power input | kW | 1.59 | 2.08 | 2.54 | 3.26 | |
| COP | W/W | 4.03 | 4.16 | 4.26 | 4.36 | |
| Cooling | Nominal capacity | kW | 6.7 | 9.02 | 10.24 | 14.74 |
| Power input | kW | 1.72 | 2.38 | 2.78 | 4.14 | |
| EER | W/W | 3.89 | 3.79 | 3.69 | 3.56 | |
| DHW | Nominal capacity | kW | 5.78 | 7.78 | 9.83 | 12.55 |
| Power input | kW | 1.86 | 2.43 | 2.93 | 3.78 | |
| COP | W/W | 3.1 | 3.2 | 3.35 | 3.32 | |
| Power supply | V/Ph/Hz | 220~240/1/50 | ||||
| Max. leaving water temperature (without using backup heater) | ℃ | 55 | ||||
| Working ambient range | ℃ | -25 – 43 | ||||
| Refrigerant type | R410A | |||||
| Compressor | TOSHIBA Ratory | DAIKIN Scroll | ||||
| Net Dimensions HxWxD | mm | 1070*1140*480 | 1275*1205*480 | 1480*1200*480 | ||
| Net weight | kg | 125 | 130 | 179 | 200 | |
| Noise level | dB(A) | 53 | 53 | 55 | 58 | |
